    LPJM05125HENL 2.5G Base-T Single Port RJ45 PoE+ MagJack Tab Down With Green&Yellow Led

    Ask Lasest Price
    Brand Name : LINK-PP
    Model Number : LPJM05125HENL
    Certification : UL,ROHS,Reach,ISO
    • Product Details
    • Company Profile

    LPJM05125HENL 2.5G Base-T Single Port RJ45 PoE+ MagJack Tab Down With Green&Yellow Led

    LINK-PP LPJM05125HENL 2.5G Base-T RJ45 MagJack for Video Recorder and Satellite ( POE+,Single Port, Tab Down, Green/Yellow Led)


    The LPJM05125HENL supports speed 2.5G Base-T, It is compliant to IEEE 802.3 at, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Smart Meters, Solar Inverter, Automation and Video Recorder.


    LINK-PP Part Number:
    LPJM05125HENLConnector Type
    Jack
    Part Status
    ActiveMounting Type
    Through Hole
    Application-Lan
    Ethernet(PoE+)
    Speed
    2.5G Base-T
    Number of Ports
    1x1 PortCores per Port
    8
    Latch
    DownLED Option
    Green/Yellow
    Orientation
    90° Angle (Right)PCB Mount Angle

    SIDE ENTRY

    Shield EMI Tabs
    WithoutTemperature

    0℃ TO 70℃

    PCB
    FR4PCB Retaining Post

    T POST

    Package Height (Inches/mm)
    0.524/13.30Package Length (Inches/mm)

    0.837/21.25

    Package Width (Inches/mm)
    0.627/15.93
    Contact Mating Area Plating

    GOLD 6u"/15u"/30u"

    Bst Circuit
    YesAutomDX

    YES

    Diodes
    NoConfiguration RX/TX

    T,C

    Turns Ratio RX/TX
    1CT:1CT
